6S 24V 20A BMS Protection Board with Balance
● In Stock
| SKU | 6S BMS |
| Category | BMS |
| Availability | In Stock |
| Shipping | Countrywide delivery · Free on orders over KSh10,000.00 |
Description
The 6S 24V 20A BMS Battery Protection Board is designed for building and protecting 6-series (6S) lithium-ion battery packs, including packs made from 18650 cells. It provides essential battery management functions such as overcharge, over-discharge, over-current and short-circuit protection, while integrated cell balancing helps maintain more consistent voltage across the individual cells. Designed for a 6S lithium-ion configuration, the board supports a nominal pack voltage of approximately 22.2V and a fully charged voltage of 25.2V when standard 3.7V/4.2V Li-ion cells are used. It is commonly marketed as a 24V BMS because it is intended for the 24V-class battery systems. With a rated current of up to 20A, this BMS is suitable for applications such as electric bicycles, scooters, solar lighting systems, portable battery packs, robotics and other rechargeable lithium battery projects.
Key Features
- Designed for 6S lithium-ion battery packs
- Commonly used with 18650 Li-ion cells
- 20A rated current
- Nominal battery pack voltage of 22.2V
- Maximum fully charged pack voltage of 25.2V
- Integrated cell balancing
- Overcharge protection
- Over-discharge protection
- Over-current protection
- Short-circuit protection
- Helps maintain balanced cell voltages
- Compact PCB design
- Suitable for rechargeable battery-pack construction
- Ideal for e-bikes and electric scooters
- Suitable for solar lighting and energy-storage projects
Specifications
| Specification Details | |
| Product Type Lithium Battery BMS / Protection PCB | |
| Battery Chemistry Li-ion / Lithium-Ion | |
| Cell Configuration 6S | |
| Compatible Cells 18650 and other compatible Li-ion cells | |
| Nominal Cell Voltage 3.7V | |
| Maximum Cell Voltage 4.2V | |
| Nominal Pack Voltage 22.2V | |
| Maximum Pack Voltage 25.2V | |
| Common System Rating 24V | |
| Rated Current Up to 20A* | |
| Cell Balancing Yes | |
| Overcharge Protection Yes | |
| Over-Discharge Protection Yes | |
| Over-Current Protection Yes | |
| Short-Circuit Protection Yes | |
| Charging Configuration 6S Li-ion | |
| PCB Type Battery Management System | |
| Applications E-bike, scooter, solar lighting, battery packs | |
| Weight Approximately 20g | |
| Battery Voltage Guide | |
| For standard 3.7V nominal / 4.2V maximum Li-ion cells | |
|---|---|
| 6 × 3.7V = 22.2V nominal | |
| 6 × 4.2V = 25.2V fully charged | |
| This is why a 6S Li-ion BMS may be sold as a 24V BMS, even though a fully charged battery pack reaches approximately 25.2V. | |
| Typical Applications | |
| Suitable for 24V-class e-bike battery packs, electric scooters, solar lighting systems, robotics, DIY 18650 battery packs, portable power systems, electric tools and other 6S lithium-ion applications. | |
| Important Note | |
| This board is intended for a 6S lithium-ion battery pack. Use a charger designed for 6S Li-ion batteries with a 25.2V charging voltage. A BMS provides battery protection and balancing but does not replace the correct lithium battery charger. | |
What's in the Box
- 1 × 6S 24V 20A Li-Ion BMS Protection Board with Balance
