MLX90614ESF Non-Contact Infrared Temperature Sensor
● Sold Out
| SKU | AT-0239 |
| Category | Sensors |
| Availability | Sold Out |
| Shipping | Countrywide delivery · Free on orders over KSh10,000.00 |
Description
Designed to measure surface temperature without physical contact, the MLX90614ESF Non-Contact Infrared Temperature Sensor is a high-precision digital thermometer. Using advanced infrared thermopile technology and an onboard 16-bit ADC , it detects thermal radiation emitted by objects and outputs accurate temperature readings via I2C communication . This sensor is widely used in medical devices, industrial systems, and IoT projects where contactless temperature monitoring is essential. It can measure both object temperature and ambient temperature , providing stable performance and high accuracy across a wide range of environmental conditions. Compatible with Arduino, ESP32, and Raspberry Pi
Key Features
- Accurate, contactless temperature measurement.
- Measures both object and ambient temperature simultaneously.
- Simple I2C interface for quick integration with microcontrollers.
- Low power consumption and high noise immunity.
- Suitable for mobile, industrial, and IoT applications.
Specifications
| Model | MLX90614ESF |
|---|---|
| Sensor Type | Non-contact infrared thermometer |
| Operating Voltage | 3.3V – 5V DC |
| Communication Interface | I2C (SMBus compatible) |
| Measuring Range | Object Temperature: -70°C to +380°C |
| Ambient Temperature | -40°C to +125°C |
| Accuracy | ±0.5°C (typical in room temperature range) |
| Resolution | 0.02°C |
| Field of View (FOV) | Approx. 35° |
| Response Time | 0.1 – 1 second (configurable) |
| Output Type | Digital data via I2C bus |
| Built-in Components | Low noise amplifier and 17-bit ADC |
| Compatibility | Arduino, Raspberry Pi, ESP8266, ESP32, STM32, etc. |
| Dimensions | Compact module with 4-pin interface (VCC, GND, SDA, SCL) |
