SRD-12VDC-SL-C 5V Relay | 10A Power Relay Module for Arduino, ESP32 & Raspberry Pi

KSh65.00 KSh70.00 -7%

● In stock (25 available)

SKU	AT-0192
Category	Actuators & Motors
Availability	In stock
Shipping	Countrywide delivery · Free on orders over KSh10,000.00

Description

The SRD-12VDC-SL-C 12V Relay Module is a reliable electromechanical switching device used to control high-voltage or high-current loads using low-voltage control signals from Arduino, ESP32, STM32, or Raspberry Pi . This relay provides complete isolation between the control circuit and load, ensuring safe operation when switching devices like lights, fans, motors, solenoid valves, and appliances . With its standard 12V coil voltage and 10A switching capacity , it’s ideal for home automation, IoT, and smart control systems .

Key Features

Controls AC or DC loads using microcontroller signals.
High current capacity (up to 10A) – suitable for household appliances.
Compact and reliable SRD relay design.
Electrical and mechanical isolation for safety.
Compatible with Arduino and Raspberry Pi relay libraries.
Long lifespan and stable operation.

Specifications

Model	SRD-12VDC-SL-C
Relay Type	SPDT (Single Pole Double Throw)
Coil Voltage	12V DC
Trigger Voltage	12V (logic compatible with Arduino, ESP32, STM32)
Contact Rating	10A @ 250VAC / 10A @ 30VDC
Contact Resistance	≤ 100 mΩ
Insulation Resistance	≥ 100 MΩ (at 500VDC)
Switching Time	≤ 10ms (operate) / ≤ 5ms (release)
Mechanical Life	10 million operations
Electrical Life	100,000 operations
Operating Temperature	–40°C to +85°C
Dimensions	Approx. 19 × 15 × 15 mm
Mounting Type	PCB through-hole
