Infrared Receiver Sensor Module 38kHz Digital IR Sensor for Arduino, Remote Control & DIY Electronics

KSh150.00

● In stock (25 available)

SKU	AT-0128
Category	Sensors
Availability	In stock
Shipping	Countrywide delivery · Free on orders over KSh10,000.00

Description

The 38kHz Infrared Receiver Sensor Module is a compact electronic building block used to receive and decode infrared signals transmitted at the standard 38kHz frequency. It is commonly used with TV remotes, IR transmitter modules, and custom remote-control systems. The module contains a highly sensitive IR receiver sensor such as VS1838B or HX1838 mounted on a small PCB with indicator components and a simple 3-pin interface. It can be directly connected to Arduino, ESP32, Raspberry Pi, STM32, and other microcontrollers. When paired with an IR transmitter module, it enables wireless communication for remote-controlled devices, automation systems, and robotics projects.

Key Features

Receives standard 38kHz infrared signals
Compatible with TV remotes and IR transmitter modules
Works with Arduino, ESP32, Raspberry Pi, STM32, and other microcontrollers
High sensitivity and stable signal reception
Simple 3-pin interface for easy wiring
Compact module suitable for DIY electronics and robotics
Low power consumption and reliable performance
Ideal for wireless control and infrared communication projects

Specifications

Module Type	IR Infrared Receiver Sensor Module
Receiving Frequency	38kHz
Sensor Type	Digital IR Receiver
Compatible Receiver IC	VS1838B / HX1838 / TSOP1738
Operating Voltage	3.3V – 5V DC
Output Type	Digital Signal
Detection Distance	Up to 5 – 10 meters
Viewing Angle	Approx. 35° – 60°
Interface Pins	GND, VCC, OUT / DA
PCB Color	Black
Module Dimensions	Approx. 24 mm × 19 mm × 8 mm
Approximate Weight	1 g – 3 g
GND	Ground
VCC	3.3V – 5V Power Supply
OUT / DA	Digital Signal Output
